INTERNATIONAL J/111 CLASS RULES Version 2012 - 02 Effective Date: 1 April 20122 J/111 Class Rules

INTRODUCTION

Prior to the Class being formed with suitable By-Laws in place and with at least 50

active owners, J Boats Inc. (J/111 copyright and trademark holder) shall take the

position of the Class Association and the Executive Committee. Please contact

info@jboats.com with any inquiries.

This introduction only provides an informal background and the International J/111 Class

Rules proper begin on the next page.

The J/111 Class has been created as a strict one-design Class where the true test when

racing is between crews and not boats and equipment. The fundamental objective of these

class rules is to ensure that this concept is maintained.

J/111 hulls, hull appendages and rigs shall be manufacturer controlled and shall only be

produced by a manufacturer licensed by J Boats, Inc.. Equipment is built in accordance with

the J/111 Building Specification and Configuration Manual. These parts having left the

manufacturer may only be altered to the extent permitted in Section C of the class rules.

J/111 sails are measurement controlled to control all the primary dimensions but may be

made by any manufacturer. In order to confirm compliance with the class rules sails are

required to be certified by an official measurer or by a manufacturer licensed under the

ISAF In House Certification. These parts may only be altered to the extent permitted in

Section C of the class rules after certification control has been performed.

Rules regulating the use of equipment during a race are contained in Section C of these class

rules, in ERS Part I and in the Racing Rules of Sailing.

THESE RULES ARE CLOSED CLASS RULES WHERE IF IT DOES NOT

SPECIFICALLY SAY THAT YOU MAY – THEN YOU SHALL NOT.

COMPONENTS, AND THEIR USE, ARE DEFINED BY THEIR DESCRIPTION.J/111 Class Rules 3

PART I – ADMINISTRATION

Section A – General

A.1 LANGUAGE

A.1.1 The official language of the class is English and in case of dispute over translation

the English text shall prevail.

A.1.2 The word “shall” is mandatory and the word “may” is permissive.

A.1.3 Except where used in headings, when a term is printed in “bold” the definition in the

ERS applies and when a term is printed in “italics” the definition in the RRS applies.

A1.4. Section in Blue Text are only relevant once the class gains ISAF Status

A.2 ABBREVIATIONS

A.2.1 ISAF International Sailing Federation

MNA ISAF Member National Authority

ICA International J/111 Class Association

NCA J/111 National Class Association

ERS Equipment Rules of Sailing

RRS Racing Rules of Sailing

OSR Offshore Special Regulations (www.sailing.org/specialregs)

LM Licensed Manufacturer by J/Boats, Inc.

A.3 AUTHORITIES

A.3.1 The international authority of the class is ISAF which shall co-operate with the ICA

in all matters concerning these class rules.

A.3.2 Notwithstanding anything contained herein, the certification authority has the

authority to withdraw a certificate and shall do so on the request of the ISAF.

A.3.3 Neither the certification authority nor an official measurer, an international

measurer or an equipment inspector is under any legal responsibility in respect of

these class rules or the accuracy of measurement. No claim arising from them shall

be entertained.

A.4 ADMINISTRATION OF THE CLASS

A.4.1 ISAF has delegated its administrative functions of the class excluding sails to the

ICA.

A.4.2 ISAF has delegated its administrative functions of the class in regard to sails to

MNAs. The MNA may delegate part or all of its functions, as stated in these class

rules, to an NCA.

A.4.3 In countries where there is no MNA, or the MNA does not wish to administrate the

class, its administrative functions as stated in these class rules shall be carried out

by the ICA which may delegate the administration to an NCA.4 J/111 Class Rules

A.5 CLASS RULES CHANGES

A.5.1 Amendments to these class rules shall be proposed inline with the constitution and

are subject to the approval of J/Boats.

A.5.1 Amendments to these class rules shall be proposed inline with the constitution and

are subject to the approval of the ISAF in accordance with the ISAF Regulations.

A.5.2 Amendments to the configuration manual shall be proposed inline with the

constitution and are subject to the approval of J/Boats and ISAF in accordance with

the ISAF Regulations.

A.5.3 Amendments to the construction manual are subject to the approval of J/Boats and

the ISAF Secretariat Technical Department.

A.6 RULES CHANGES AT EVENTS

A.6.1 At all events ISAF Regulation 10.5(f) applies.

A.6.2 Except that the Notice of Race or Sailing Instructions may change the following

rules:

(a) Require additional safety equipment to the minimums defined in Section C.

A.6.3 For events other than National, Continental or World Championship the race

organisers may apply to the Executive Committee to vary the following rules:

(a) permit additional Group 3 sailors. Any change should be posted in the Notice of

Race not less than 30 days before the regatta unless unanimously agreed by the

entered boats.

(b) increase the number of sails carried and used aboard.

A.7 RULES INTERPRETATION

A.7.1 Interpretation of ERS shall be made in accordance with the ISAF Regulations.

A.7.2. Interpretation of class rules shall be made by the Class Executive Committee.

A.7.2 Interpretation of class rules shall be made in accordance with the ISAF

Regulations.]

A.7.3. Interpretation of the configuration manual shall be made by the Class Executive

Committee and J/Boats in consultation with the ISAF.

A.7.4. Interpretation of construction manual shall be made by J/Boats in consultation with

ISAF.

A.8 INTERNATIONAL CLASS FEE AND ISAF BUILDING PLAQUE

A.8.1 ISAF shall, after having received the International Class Fee for the hull, send the

ISAF Building Plaque and a measurement form to the licensed hull builder.]

A.9 SAIL NUMBERS

A.9.1 Sail numbers shall be issued by the MNA.

A.10 HULL MANUFACTURER DECLARATION

A.10.1 A Manufacturer’s declaration shall record the following information:

(a) Class

(b) Quality Control Manufacturer StatementJ/111 Class Rules 5

(c) Hull identification number

(d) Builder/Manufacturers details

(e) Date of issue of initial manufacturer’s declaration

(f) Section D & E - Modification, Maintenance and Repair details

A.11 VALIDITY OF MANUFACTURER DECLARATION

A.11.1 A manufacturer declaration becomes invalid upon:

(a) the change to any items recorded on the declaration as required

(b) withdrawal by the ISAF or LM

(c) the issue of a new manufacturer declaration

A.12 RE-ISSUE OF MANUFACTURER DECLARATION

A.12.1 The LM may re-issue a Manufacturer Declaration to a hull, if the hull conforms to

the class rules.:

(a) when it is invalidated under A.11.1(a) or (b).

(b) when it is invalidated under A.10.1(f) at its discretion and any remedial work

shall be recorded on the re-issued declaration

(c) in case of loss

(d) at the request of ISAF

A.13 RETENTION OF DOCUMENTATION

A.13.1 The skipper shall retain the currently issued manufacturer declaration.

A.13.2 A copy of the manufacturer declaration shall be retained by the LM and a copy shall

be sent to the ICA. 6 J/111 Class Rules

Section B – Boat Eligibility and Equipment Inspection

For a boat to be eligible for racing, it shall comply with the rules in this section.

B.1 CLASS RULES AND CERTIFICATION

B.1.1 The boat shall:

(a) be in compliance with the class rules.

(b) have a valid manufacturer's declaration.

(c) have valid certification marks on all sails used for class racing.

B.2 CLASS ASSOCIATION MARKINGS

B.2.1 A valid Class Association Sticker, if required by the NCA or the ICA, shall be

affixed to the hull in a conspicuous position.

B.3 EQUIPMENT INSPECTION

B.3.1 In the case of a dispute at an event alleging non-compliance with class rules and

building specification and construction manual where specific measurements are not

stated, the Event Equipment Inspector shall adopt the following procedure:

a) A sample measurement of the disputed item shall be obtained by taking the

identical measurement from a randomly selected group of boats or items of

equipment (control group).

b) The measurement of the disputed boat or items of its equipment, taken using the

same technique as above, shall be compared to the sample.

c) If any of the measurements obtained from the disputed boat or item of

equipment lie outside the corresponding range of measurements found in the

control group, the matter together with the details of the measurement methods

and any other relevant information shall be referred to the Race Committee.

B.4 EVENT LIMITATION MARKS

B.4.1 If an event uses event limitation marks these marks shall not be removed during

the event. If the event limitation mark becomes damaged or lost this shall be

reported to the race committee as soon as possible.J/111 Class Rules 7

PART II – REQUIREMENTS AND LIMITATIONS

The crew and the boat shall comply with the rules in Part II when racing. In case of conflict

Section C shall prevail.

The rules in Part II are closed class rules.

Section C – Conditions for Racing

C.1 GENERAL

C.1.1 RULES

(a) ISAF Offshore Special Regulations - Category 4

(See www.sailing.org/specialregs)

(b) The ERS Part I – Use of Equipment shall apply.

C.2 ADVERTISING

C.2.1 LIMITATIONS

Advertising shall only be displayed in accordance the ISAF Advertising Code. (See

ISAF Regulation 20)

C.3 CREW

Whilst racing under these class rules, the ISAF Sailor Classification Code

Regulation 22 applies. All Group 1 competitors shall hold valid classifications.

Competitors who are unclassified or expired will be deemed to be Group 3.

(Competitors requiring a classification should apply on the ISAF website

www.sailing.org/classification)

C.3.1 LIMITATIONS ON THE CREW

(a) The crew shall be Group 1 Competitors and up to one non-Group 1 Competitor,

and non-Group 1 competitors of 65 years of age or older. In addition, the crew

may include one non-Group 1 Competitor who is a full time employee of J

Boats, Inc. or a J Boats dealer or is the J/111 class manager.

(b) No crew member shall be substituted during an event of 5 or less consecutive

days or that has required a crew declaration as part of registration, without the

approval of the race committee.

C.3.2 LIMITATIONS ON THE DRIVER

The Driver shall meet the following criteria except in the event of an emergency

involving the safety of the boat or crew where the boat may be steered by any crew

member. Any such incident shall be reported to the protest committee which may

penalize the boat. The penalty may be less than disqualification.

(a) Permitted Drivers:

(i) Owner - a crew who legally owns and pays 50% of the yacht and the running

costs; or a crew with a current Group 1 classification who is at least a 33%

partner in the purchase of the complete yacht and the running costs.

(ii) Family Member - an immediate family member of the Owner who is

approved by the class executive committee.8 J/111 Class Rules

(iii) Regular Crew Member - a bonafide Group 1 Competitor who sailed with the

Owner in at least 50% of the events the Owner participated in during the

prior 12 months, and who is approved by the class executive committee.

(iv) Charterer – an Owner, Family Member or bonafide Group 1 charterer

confirmed by the Owner of the boat for that event, and who is approved by

the class executive committee.

(b) For day-racing events of five or less consecutive days, not more than two

Drivers can be designated, at least one of which must be an Owner. From five

minutes before the start until the finish, the boat shall be helmed by the

designated Driver(s) except for momentary absences for personal or shipboard

needs not to exceed five (5) minutes where a Group 1 crew may drive.

C.3.3 WEIGHTS

minimum maximum

The total weight of the crew dressed in shorts

and T-shirt

650 kg

C.4 PERSONAL EQUIPMENT

C.4.1 MANDATORY

(a) The boat shall be equipped to the minimum standard ISAF Offshore Special

Regulations Category IV.

C.5 PORTABLE EQUIPMENT

C.5.1 MANDATORY

(a) As required by the Offshore Special Regulations Category IV.

(b) One anchor of not less than 4.4kg and combined anchor and chain of not less

7.25kg. This shall be attached to not less than 48m of line of not less than

12mm in diameter.

C.6 BOAT

C.6.1 WEIGHT

minimum maximum

The weight of the boat in dry condition 4,250 kg

The weight shall be taken excluding sails and all portable equipment as listed in

C.5. When the boat weight is less than the minimum requirement, corrector

weights shall be permanently fastened in accordance with Appendix H-3.

C.6.2 MODIFICATIONS, MAINTENANCE AND REPAIR

The following is permitted without prior approval. Unless stated otherwise items

mentioned in this section may be obtained by any manufacturer or supplier.

(a) Tactical / navigation / communication equipment may be installed.

(b) Deck and rig fittings may be replaced on a like for like basis.J/111 Class Rules 9

C.7 HULL

C.7.1 MODIFICATIONS, MAINTENANCE AND REPAIR

The following is permitted without prior approval. Unless stated otherwise items

mentioned in this section may be obtained from any manufacturer or supplier.

MODIFICATIONS

(a) Placement of line bags, winch handle holders and other storage devices.

(b) Placement of additional fairleads and cleats.

(c) Location and installation and type of bow and stern mooring eye.

(d) Foredeck lifeline netting, shroud and lifeline rollers and other anti-chafing gear.

(e) Padeyes and related rigging for barber hauling the jib either inboard or outboard

from the standard jib track locations. Installation of rail mounted jib track with

plunger style jib car for outboard jib leads.

(f) Spinnaker sheet tweekers led to stanchion bases or midship pad eyes, with

additional cam cleats.

(g) Re-leading the single-ended outhaul, cunningham and/or boom vang to either

the cockpit or dual leads port and starboard.

(h) Foot braces, hand holds, and nonslip material to promote save movement on

deck.

(i) Carbon fibre steering wheel.

(j) Use of a shackle or similar device to attach headsail sheets to sails, the tack line

to the spinnaker, the mainsail tack to gooseneck and the headsail head and tack

to the furling system.

(k) The use of a snap shackle or other securing device attached to a stanchion base

or shroud to secure the spinnaker halyard while the spinnaker is not in use.

(l) The use of a second clutch or jammer for the main and headsail halyards.

(m) Installation of additional lighting and instrumentation brackets on the mast.

(n) Interior cruising and day sailing amenities that do not enhance performance.

MAINTENANCE

(o) Routine maintenance is allowed to the interior of the boat.

(p) Below the waterline the hull may be lightly sanding to be keyed for painting,

antifouling or polishing. Minor imperfections to the hull surface may be faired.

(q) Waxing and polishing of the hull external surfaces may be done above the

waterline.

(r) The hull topside gelcoat surface shall not be removed except for light sanding

prior to painting.

(s) Fairing and painting hull over the keel flange and within 100 mm of the keel

flange hull recess is permitted.

(t) Holes may be made and local reinforcement in the hull for the fitting of

electronic navigation systems.

REPAIR

(u) Gelcoat scratch and minimal damaged areas may be repaired.10 J/111 Class Rules

C.8 HULL APPENDAGES

C.8.1 MODIFICATIONS, MAINTENANCE AND REPAIR

The following is permitted without the approval of the LM. Unless stated otherwise,

items mentioned in this section may be obtained by any manufacturer or supplier.

MODIFICATIONS

(a) Minor imperfections on the keel and rudder may be faired using compounds

such as polyester or epoxy resins which may have low density bulking agents

such as micro-balloons added, provided that the standard shape and dimensions

of the keel and rudder are not altered.

(b) The keel and rudder may be lightly sanded for the purpose of keying and

antifoul may be applied.

(c) The leading edge of the keel may be fitted with a kelp cutter.

MAINTENANCE AND REPAIR

(d) Appendages may be lightly sanded for keying and then repainted or recoated.

C.9 RIG

C.9.1 MAST

(a) DIMENSIONS

b) USE

(1) The mast shall remain fixed at the deck and at the mast step for the duration

of an event of 5 or less consecutive days.

C.9.2 BOOM

(a) DIMENSIONS

minimum maximum

Limit mark width 20mm

Outer point distance 4420mm

(b) USE

(1) The intersection of the aft edge of the mast spar and the top of the boom

spar, each extended as necessary, shall not be below the upper edge of the

mast lower limit mark when the boom spar is at 90° to the mast spar.

C.9.3 BOWSPRIT

(a) USE

(1) When retracted, the forward end shall not extend more than 80 mm forward

of the hull.

(2) To extend the bowsprit a boat shall be in the process of either a continuous

hoist, flying or a continuous retrieval of the gennaker. At all other times

the bowsprit shall be retracted. J/111 Class Rules 11

C.9.4 STANDING RIGGING

(a) DIMENSIONS

(b) USE

(1) Rigging screws shall not be adjusted while racing (backstay adjustment is

permitted).

C.9.5 RUNNING RIGGING

(a) USE

(1) Running rigging shall not be used to pull the top of the mast forward while

sailing offwind, such as rigging a spare halyard to the foredeck or

overtensioning the jib sheets when the headsail is furled.

C.9.6 MODIFICATIONS, MAINTENANCE AND REPAIR

The following is permitted without the approval of the LM. Unless stated otherwise

items mentioned in this section may be obtained any manufacturer or supplier.

MODIFICATIONS

(a) A watertight seal, tape or other material may be added around the bowsprit spar.

(b) A flexible batten may be added to the end of the bowsprit to catch the lazy

gennaker sheet.

MAINTENANCE AND REPAIR

(c) Normal servicing or replacement on a like for like basis of running rigging and

fittings.

(d) Standing Rigging and backstay may be replaced provided it conforms to the

specification defined in the configuration manual.

C.10 SAILS

C.10.1 LIMITATIONS

(a) Not more than 1 Mainsail, 2 Headsails, 2 Asymmetric Spinnakers, 1 Class

Heavy Weather Jib, 1 Storm Trysail and 1 Storm Jib may be used during an

event of 5 or less consecutive days or when the class royalty numbers have been

required as part of registration.

C.10.2 MAINSAIL

(a) IDENTIFICATION

The national letters and sail numbers shall comply with the RRS except where

prescribed otherwise in these class rules.

(b) USE

(1) The sail shall be hoisted on a halyard.

(2) The highest visible point of the sail, projected at 90° to the mast spar, shall

not be set above the lower edge of the mast upper limit mark. The

intersection of the leech and the top of the boom spar, each extended as

necessary, shall not be behind the fore side of the boom outer limit mark.

(3) Luff of the mainsail shall be in the spar grooves or attached to a mainsail

luff slide or luff car system.

(4) The tack ring of the mainsail shall be affixed in the standard tack fitting.

(5) The clew ring shall be attached to the outhaul and down to the boom. 12 J/111 Class Rules

C.10.3 HEADSAILS AND CLASS HEAVY WEATHER JIB

(a) USE

(1) Luff bolt ropes shall be in the headsail groove.

(2) The jib shall be attached to the standard roller furling system.

(3) The Class Heavy Weather Jib must be capable of furling, except in the

event of a damaged headfoil, when the jib may be attached via a secondary

means, but only while no other headsail or spinnaker is set.

C.10.4 STORM JIB

(a) USE

(1) May not be used while a spinnaker or another headsail is set.

C.10.5 ASYMMETRIC SPINNAKER

(a) IDENTIFICATION

The sail numbers shall comply with the RRS except where prescribed otherwise

in these class rules.

(b) USE

(1) A spinnaker retrieval line is permitted to be attached to the sail.

C.10.6 MODIFICATIONS AND REPAIR

(a) No sail may be modified or re-cut and then used without recertification.

(b) During a class event, no sail may be modified or re-cut.

(c) If a sail has been lost or damaged it may be repaired or replaced only with the

approval of the race committee or fleet captain.

(d) Battens of any material shall be placed in the batten pockets on the mainsail

and may be placed in headsails

C.10.7 SAIL PURCHASE LIMITS – Planned for 2013.

Section D – Hull

D.1 GENERAL

D.1.1 RULES

(a) The hull shall comply with the class rules in force at the time of initial

certification.

D.1.2 DEFINITIONS

(a) HULL DATUM POINT

The hull datum point is TBD

D.1.3 IDENTIFICATION

(a) moulded-in hull identification number assigned by a Builder authorized by

J/Boats Inc

(b) From hull number _____ onwards an ISAF Plaque permanently placed on the

starboard aft cockpit side.

D.1.4 BUILDERS

(a) The hull shall built by a builder licensed by J/Boats Inc.J/111 Class Rules 13

(b) All moulds shall be approved by J/Boats Inc. and ISAF.

D.1.5 MODIFICATIONS, MAINTENANCE AND REPAIR

The following may be done by a LM, or by anybody after a formal request has been

made to the LM and written approval is received by the owner. This shall require the

manufacturer’s declaration to be re-issued stating the work done.

MODIFICATIONS, MAINTENANCE AND REPAIR

(a) If any hull is damaged and requires to be repaired in any other way than

described in section C.

Section E – Hull Appendages

E.1 GENERAL

E.1.1 RULES

(a) Hull appendages shall comply with the class rules in force at the time of

manufacturer except those rules in Section C where the current rules take

precedence.

E.1.2 MODIFICATIONS, MAINTENANCE AND REPAIR

The following alterations may be made by a LM, or by anybody after a formal

request has been made to the LM and written approval is received by the owner.

This shall require the manufacturer’s declaration to be re-issued

(a) If any hull appendage is damaged and requires to be repaired in any other way

than described in section C the details shall be recorded on the Manufacturers

declaration.

E.1.3 MANUFACTURERS

(a) The hull appendages shall be made by manufacturers licensed by J/Boats Inc.Section F – Rig

F.1 PARTS

F.1.1 MANDATORY

(a) Mast

(b) Boom

(c) Standing rigging

(d) Running rigging

(e) Bowsprit

F.2 GENERAL

F.2.1 MANUFACTURER

(a) Spars shall only be supplied by a licenced manufacture and built in

accordance with the manufacturing specification.

F.2.2 RULES

(a) The spars and their fittings shall comply with the class rules in force at

the time of manufacturer of the spar except those rules in Section C

where the current rules take precedence.

(b) The standing and running rigging shall comply with the class rules.

F.2.3 MODIFICATIONS, MAINTENANCE AND REPAIR

The following alterations may be made by a LM, or by anybody after a formal

request has been made to the LM and written approval is received by the

owner. This shall require the manufacturer’s declaration to be re-issued.

(a) If any spar is damaged and requires repair in any other way than described

in section C the details shall be recorded on the Manufacturer's

declaration.

F.2.3 MANUFACTURER

(a) Spars shall only be supplied by a licensed manufacturer.

Section G – Sails

G.1 GENERAL

G.1.1 RULES

(a) Sails shall comply with the class rules in force at the time of certification.

G.1.2 CERTIFICATION

(a) The official measurer or In-House Official Measurer shall certify

mainsails and headsails in the tack and spinnakers in the head and shall

sign and date the certification mark.

(b) The ISAF or an MNA may appoint one or more In-House Official

Measurers to measure and certify sails produced by that manufacturer..G.1.3 SAILMAKER

(a) No licence is required.

(b) For spinnakers the weight in g/m

2

of the body of the sail shall be indelibly

marked near the head point by the sailmaker together with the date and

his signature or stamp. For sails certified after 1 January 2012, in addition

the maker and style of sail cloth shall be marked by the sailmaker.

G.1.4 J/111 SAIL ROYALTY LABEL

Effective January 1, 2013, each sail (excluding the Class Heavy Weather Jib

and storm sails) shall have permanently fixed in its tack, a numbered class

royalty label. Labels shall only be available from the Class. The label shall not

be transferred from one sail to another.

G.1.5 MODIFICATIONS, MAINTENANCE AND REPAIR

If any sail is damaged and requires repair in any other way than described in

section C, the sail will require re-certification which may require

fundamental measurement.

G.2 MAINSAIL

G.2.1 IDENTIFICATION

(a) The class insignia available from J/Boats shall conform with the

dimensions in Appendix H-1.

G.2.2 MATERIALS

(a) The ply fibres shall consist of woven ply and/or laminated ply made from

one or more of the following materials: polyester, aramid, PEN, HMPE

and carbon fiber.

(b) Sail reinforcement shall be made from one or more of the following

materials: polyester, aramid, PEN, HMPE and carbon fiber.

(c) Battens of any material.

G.2.3 CONSTRUCTION

(a) The construction shall be: soft sail; single ply or laminated ply sail.

(b) The sail shall be constructed with at least one serviceable set of reef points,

meaning one point adjacent to the luff, one point adjacent to the leech and

four corresponding points in the body of the sail. The lowest set of reef

points shall be installed no closer than 1500 mm to the foot.

(c) The mainsail shall have five batten pockets in the leech. The top batten

pocket shall be full length extending from luff to leech. Other battens

pockets may be of any length.

(d) The following are permitted: Stitching, glues, tapes, bolt ropes, corner

eyes, headboard with fixings, Cunningham eye or pulley, batten pocket

patches, batten pocket elastic, batten pocket end caps, mast and boom

slides, leech line with cleat, one window, tell tales, sail shape indicator

stripes and items as permitted or prescribed by other applicable rules.

(e) The leech shall not extend aft of straight lines between:(1) the aft head point and the intersection of the leech and the upper edge

of the nearest batten pocket,

(2) the intersection of the leech and the lower edge of a batten pocket

and the intersection of the leech and the upper edge of an adjacent

batten pocket below,

(3) the clew point and the intersection of the leech and the lower edge of

the nearest batten pocket.

G.2.4 DIMENSIONS

Half width 3080 mm

Three-quarter width 1880 mm

Mainsail upper leech point is defined as the point

on the leech equidistant from the head point and the

three quarter leech point.

Upper width 1060 mm

Head width 210 mm

Head point to intersection of leech and centreline

of uppermost batten pocket

2400 mm 2420 mm

The weight of the mainsail (without battens) 18 kg

G.3 HEADSAIL

G.3.1 MATERIALS

(a) The ply fibres shall consist of woven ply and/or laminated ply made from

one or more of the following materials: polyester, aramid, PEN, HMPE

and carbon fiber.

(b) Sail reinforcement shall be made from one or more of the following

materials: polyester, aramid, PEN, HMPE and carbon fiber.

G.3.2 CONSTRUCTION

(a) The construction shall be: soft sail; single ply or laminated ply sail.

(b) The headsail shall have no more than 4 batten pockets in the leech.

Batten material is optional.

(c) The following are permitted: Stitching, glues, tapes, corner eyes, batten

pocket elastic, batten pocket patches, batten pocket end caps, leech line

with cleat, one window, tell tales, sail shape indicator stripes, UV

protective may be applied to the leech and foot to cover the sail when

furled; and items as permitted or prescribed by other applicable rules.

(d) The recommended luff tape is 4.5mm to be capable with the forestay foil.G.3.3 DIMENSIONS

G.4 CLASS HEAVY WEATHER JIB

G.4.1 RULES

(a) Except as specified in these class rules, the sail shall comply with the

ISAF OSR heavy weather jib requirements.

G.5 ASYMMETRIC SPINNAKER

G.5.1 MATERIALS

(a) The ply of the body of the sail shall be manufactured from woven nylon.

(b) At least one spinnaker carried aboard shall have the mass of ply of the

body of the sail not less than 40 g/m2. If a second spinnaker is carried, the

mass of the ply of the body of the sail shall be not less than 36 g/m2.

G.5.2 CONSTRUCTION

(a) The construction shall be: soft sail, single ply sail.

(b) The body of the sail shall consist of the same woven ply throughout.

(c) The following shall be fitted: Adjustable leech, luff and foot lines

(d) The following are permitted: Stitching, glues, tapes, corner eyes, recovery

line eyes, tell tales and items as permitted or prescribed by other applicable

rules.

G.5.3 DIMENSIONS

The area of the sail (“SA”) shall not exceed 130 square meters, based on

the formula:

Sail Area = ((luff length + leech length) x (0.25 foot length))

+ ((half width - 0.5 foot length) x ((leech length + luff length) / 3)).

minimum maximum

Luff length 14500 mm

Luff Perpendicular 4450 mm

Half width 2400 mm

Three-quarter width 1295 mm

Head width 100 mm

Foot irregularity mm

The weight of the headsail (without battens) 11.5 kg

Primary reinforcement and Secondary

reinforcement

UnlimitedSection H - Appendices

H.1 SAIL INSIGNIA

The J/111 Class insignia shall be in dark blue (or white on carbon sails) with

overall dimensions of approximately 525x900mm and shall be affixed on both

sides of the J/111 Class mainsail with the bars nearly perpendicular to a line

between the head and center of the boom and between the upper two batten

pockets.

H.2 MODEL J/111 CREW DECLARATION FORM

ISAF Sailor

ID

Classification Classification

Expiry

First Name Last Name

H.3 CORRECTOR WEIGHT LOCATION

Corrector weight shall be fixed in place under the starboard settee berth in the

main cabin. Weight may be in the form of 12 volt batteries (up to three Group

24s), lead weight, or sealed water containers.PART III – EVENT RULES

These rules must be invoked individually by the notice of race or sailing instructions.

The default is these rules do not apply. The notice of race shall state that “J/111 Class

rules Section I.….. are invoked.” For any event I.1 may not be invoked as this is an

advisory rule.

Section I

I.2 CREW WEIGHT LIMITS

The notice of race may invoke class rules I.2.1, I.2.2 or I.2.3 to replace

class rule C.3.3 the schedule of weigh in shall be included in the NOR or

be displayed on the official notice board.

I.2.1 FOR EVENTS WITH PRE REGATTA WEIGH IN

minimum Maximum

The total weight of the crew at the time of the

weigh in shorts and T shirt

650 kg

Protest during the regatta for breaches of class rule C.3.3 will not be

permitted by any competitor.

Crew substitutions are permitted at the discretion of the race committee

and shall be the only basis for re-weighing.

I.3 SUPPORT BOATS

Individual support or coach boats shall not have contact of any nature,

including

(i) communication by radio, telephone, vocal signal, visual signaling of any

kind (i.e., tactical placement, use of flags and/or different colors of

clothing) or

(ii) the transfer of crew, equipment or supplies, with a registered racing boat

from the time the boat leaves its dock or mooring each day until the boat

has finished racing for the day.

Notwithstanding the foregoing, (i) late arriving crew, food and drink may be

transferred to a racing boat prior to the first race of the day, and (ii) crew may

be transferred in the event of a unforeseen personal emergency. Infringements

of this rule will result in a penalty to the boat associated with the support boat.

Such penalty may be either penalties or disqualification at the discretion of the

protest committee or jury.
